UT Absolute angular encoder without integral bearings

Format: PDF
Size: 729.2 KB
Pages: 8
Version: V1.0
Updated: 30/05/2025

Description

This catalog details the UT series of absolute angular encoders without integral bearings. It provides technical specifications for reader heads and graduated rings, including communication protocols, mounting tolerances, and ordering information for various industrial applications.

Designed for machine manufacturers and system integrators, this document serves as a selection and installation guide for high-precision angular position feedback in rotary tables, motors, and measuring systems.

Download document

Available languages

Technical data

Power supply: 5V ±10% p. 4
Communication protocols: SSI, FANUC, FeeDat, PANASONIC, BiSS C, MITSUBISHI p. 4
Protection rating (reader head): IP 40 p. 4
Operating temperature: 0 °C to 50 °C p. 4
Storage temperature: -10 °C to 70 °C p. 4
Maximum vibration: 300 m/s² (55-2000 Hz) p. 4
Maximum shock: 1000 m/s² (11 ms) p. 4
Resolution: 23, 26, 27, 28 bits p. 5
Permissible axial movement: 0.2 mm p. 5
Relative humidity: 20% to 80% (non-condensing) p. 4
