Data Sheet Cable EC-AM-MB2
Data Sheet

Data Sheet Cable EC-AM-MB2

Document details

Format
PDF
Size
471.1 KB
Version
V1.0
Updated

Description

This data sheet provides technical specifications for the EC-AM-MB2 encoder cable, designed for absolute linear or angular encoders with Mitsubishi half duplex digital protocol. It includes pinout configurations, wiring diagrams, and details on available lengths and shielding options for connection to Mitsubishi MR-J4 drive systems.

This document is intended for machine tool integrators and maintenance technicians requiring technical details for the installation and wiring of Fagor encoders with Mitsubishi drive systems.

Download document

Available languages

Related products

Technical data

Interface
Mitsubishi half duplex digital protocol p. 1
Compatible drives
Mitsubishi MR-J4 p. 1
Available lengths
1, 3, 6, 9 meters p. 1
Shielding
Available with or without armour p. 1
Noise immunity
Ferrite core included p. 1
Supply voltage
5 V p. 1

Data extracted from the document with AI and reviewed. Check the value on the indicated page.
