Cover: Linear and rotary encoders. Standard range
Linear and rotary encoders. Standard range
Catalogs

Linear and rotary encoders. Standard range

Document details

Format
PDF
Size
1.2 MB
Pages
20
Version
V1.0
Updated

Description

This catalog provides technical specifications for Fagor's standard range of linear and rotary encoders. It details measuring methods, electrical output signals, and specific data for F series and C/C2 series linear encoders, including installation and ordering information.

Designed for machine tool manufacturers and system integrators to select and install appropriate feedback systems for precise machine positioning.

Download document

Available languages

Related products

Technical data

Max. speed (F series)
120 m/min p. 5
Max. speed (C/C2 series)
60 m/min p. 8
Operating temperature
0 °C to 50 °C p. 5
Protection rating
IP 53 (IP 64 with air) p. 5
Supply voltage
5 V ± 5% p. 4
Max. cable length (TTL)
50 m p. 4
Max. cable length (1 Vpp)
150 m p. 5
Steel tape accuracy
± 5 μm p. 5
C/C2 series accuracy
± 5 μm to ± 10 μm p. 8
Max. vibration
10 g (F series) p. 5
Weight (F series)
1.50 kg + 4 kg/m p. 5
Weight (C/C2 series)
1.2 kg + 2.5 kg/m p. 8

Data extracted from the document with AI and reviewed. Check the value on the indicated page.
